71M652X Software User’s Guide
Revision 1.7 TERIDIAN Proprietary 30 of 138
© Copyright 2005-2007 TERIDIAN Semiconductor Corporation
4.7 CREATING A PROJECT FOR THE KEIL COMPILER
4.7.1 Directory Structure
The following directory structure is established when the files from the archive 652X_Demo.zip are unpacked while
maintaining the structure of subdirectories:
:\…\meter project\
:\…\meter project\CE
:\…\meter project\CLI
:\…\meter project\CLI_652X
:\…\meter project\docs
:\…\meter project\flag
:\…\meter project\IO
:\…\meter project\Main_6521
:\…\meter project\Main_6521_CLI
:\…\meter project\Meter
:\…\meter project\Util
The project control file 652X_demo.uv2 will be in the directory :\…\meter project. The Keil compiler can be
configured easily by loading the file 652X_demo.uv2, using the Project Menu and selecting the Open Project
command.
The window shown below should appear when the project control file is opened.
