71M652X Software User’s Guide
Revision 1.7 TERIDIAN Proprietary 78 of 138
© Copyright 2005-2007 TERIDIAN Semiconductor Corporation
*M6521F (32K) only; compilation option in M6521D (16K)
**Compilation option (available Demo Code), variable present but not in use.
† Requires features not in standard demo PCB
Table 5-12: MPU Memory Location
Name Purpose Function or LSB Value CLI Format L in
bits XDATA
Whn Net metered Wh, all
elements A, LSB of W0SUM )54 signed 64 0x010B
Whn_A* Net metered Wh,
element A, for
autocalibration LSB of W0SUM )56 signed 64 0x0113
Whn_B* Net metered Wh,
element B, for
autocalibration “ )58 signed 64 0x011B
VARhn* Net metered VARh,
all elements LSB of w0sum )5C signed 64 0x012B
VARhn_A* Net metered VARh,
element A, for auto-
calibration LSB of w0sum )5E signed 64 0x0133
VARhn_B* Net metered VARh,
element B, for auto-
calibration “ )60 signed 64 0x013B
MainEdgeCnt Count of voltage zero
crossings count )64 unsigned 32 0x014B
Wh Default sum of Wh,
nonvolatile LSB of w0sum )65 signed 64 0x014F
Wh_A Wh, element A,
nonvolatile “ )67 signed 64 0x0157
Wh_B Wh, element B,
nonvolatile
“ )69 signed 64 0x015F
StatusNV Nonvolatile status See Status )6D n/a 32 0x016F
