71M652X Software User’s Guide
Revision 1.7 TERIDIAN Proprietary 112 of 138
© Copyright 2005-2007 TERIDIAN Semiconductor Corporation
Mnemonic Description Code Bytes Cycles
MOV A,Rn Move register to accumulator E8-EF 1 1
MOV A,direct Move direct byte to accumulator E5 2 2
MOV A,@Ri Move indirect RAM to accumulator E6-E7 1 2
MOV A,#data Move immediate data to accumulator 74 2 2
MOV Rn,A Move accumulator to register F8-FF 1 2
MOV Rn,direct Move direct byte to register A8-AF 2 4
MOV Rn,#data Move immediate data to register 78-7F 2 2
MOV direct,A Move accumulator to direct byte F5 2 3
MOV direct,Rn Move register to direct byte 88-8F 2 3
MOV direct1,direct2 Move direct byte to direct byte 85 3 4
MOV direct,@Ri Move indirect RAM to direct byte 86-87 2 4
MOV direct,#data Move immediate data to direct byte 75 3 3
MOV @Ri,A Move accumulator to indirect RAM F6-F7 1 3
MOV @Ri,direct Move direct byte to indirect RAM A6-A7 2 5
MOV @Ri,#data Move immediate data to indirect RAM 76-77 2 3
MOV DPTR,#data16 Load data pointer with a 16-bit constant 90 3 3
MOVC A,@A+DPTR Move code byte relative to DPTR to accumulator 93 1 3
MOVC A,@A+PC Move code byte relative to PC to accumulator 83 1 3
MOVX A,@Ri Move external RAM (8-bit addr.) to A E2-E3 1 3-10
MOVX A,@DPTR Move external RAM (16-bit addr.) to A E0 1 3-10
MOVX @Ri,A Move A to external RAM (8-bit addr.) F2-F3 1 4-11
MOVX @DPTR,A Move A to external RAM (16-bit addr.) F0 1 4-11
PUSH direct Push direct byte onto stack C0 2 4
POP direct Pop direct byte from stack D0 2 3
XCH A,Rn Exchange register with accumulator C8-CF 1 2
XCH A,direct Exchange direct byte with accumulator C5 2 3
XCH A,@Ri Exchange indirect RAM with accumulator C6-C7 1 3
XCHD A,@Ri Exchange low-order nibble indirect RAM with A D6-D7 1 3
Table 6-11: Data Transfer Operations
