71M652X Software User’s Guide
Revision 1.7 TERIDIAN Proprietary 83 of 138
© Copyright 2005-2007 TERIDIAN Semiconductor Corporation
Function/Routine
Name
Description Input Output File Name
calibrate()
processes measurements
during auto-calibration
none none calphased.c
ce_active() returns CE status none bool ce.c
ce_enable() Enables or disables the CE bool enable none ce.c
ce_init() Initializes the CE none bool ce.c
ce_reset() resets the CE none none ce.c
cli () command Line Interpreter none none cli.c
cli_init()
Initializes the SLI's interface
to any serial port.
enum SERIAL_PORT
port, enum
SERIAL_SPD speed,
bool xon_xoff
bool sercli.c3
cli0_init()
Initializes the SLI's interface
to SER0 enum SERIAL_SPD
speed, bool xon_xoff
bool ser0cli.c3
cli1_init()
Initializes the SLI's interface
to SER1 enum SERIAL_SPD
speed, bool xon_xoff
bool ser1cli.c3
cmax()
returns maximum of
unsigned char 'a' and 'b'.
uint8_t a, uint8_t b uint8_t math.c
cmd_ce () processes CE commands none none cmd_ce.c
cmd_ce_data_access
()
Processes context for CE
DATA
none none access.c
cmd_download()
downloads/uploads
code/data between various
sources and serial port
none none load.c
cmd_eeprom()
processes EEPROM
commands
none none cmd_misc.c
cmd_error()
assigns generic command
mode error result code
none none cli.c
cmd_lcd() processes "D" commands none none display.c
cmd_load()
implements user dialog for
data/code download/upload
none none load.c
cmd_meter() processes "M" commands none none meter.c
cmd_mpu_data_acces
s()
processes context for MPU
DATA
none none access.c
cmd_power_save()
processes power save
command
none none cmd_misc.c
cmd_rtc() processes RTC commands none none cmd_misc.c
cmd_trim() processes trim commands none none cmd_misc.c
cmin()
returns minimum of
unsigned char 'a' and 'b'.
uint8_t a, uint8_t b uint8_t math.c
complement_x()
x = x0 ^ 1s; takes ones-
complement of n-byte 'x0'. uint8_tx *x, uint8_tx *x0,
n
none math.c
Compute_Phase_Angl
e()
Computes the V/I phase
angle.
void void phase_angle.c
Compute_RMS() Computes Vrms and Irms. void void rms.c
