71M652X Software User’s Guide
Revision 1.7 TERIDIAN Proprietary 23 of 138
© Copyright 2005-2007 TERIDIAN Semiconductor Corporation
4 TOOL INSTALLATION GUIDE
This section provides detailed installation instructions for the Signum ADM-51 in-circuit emulator and for the Keil
compiler.
4.1 INSTALLING THE PROGRAMS FOR THE ADM51 EMULATOR
The AMD51 ICE interfaces with the PC is via the USB serial interface.
The installation process consists of the following steps:
1. Installing the Chameleon Debugger used with the Signum ICE
2. Installing the ADM51 USB driver
3. Installing
updates
4. Creating a project
4.2 INSTALLING THE WEMU PROGRAM (CHAMELEON DEBUGGER)
Insert the CD from Signum Systems and connect the ICE ADM51 to the PC with the provided USB cable.
The following dialog box will appear (this dialog box also shows the release date of the program):
Click on “Chameleon Debugger” and then select “ADM51 Emulator”.
Follow the instructions given by the installation program.
4
