C-PRO MEGA RACK & C-PRO GIGA RACK APPLICATION MANUAL
Page 53
alarm diff. pressure alarm differential > 1
PA27
Circuit 2 suction
HP alarm
setpoint .
Circuit 2 suction probe high
pressure alarm setpoint
4.0 PA25 PH02 Bar IS-S
Visible if PG01
> 1
PA28
C2 suction HP
alarm diff. Circuit 2 suction probe high
pressure alarm differential
0.5 0.0 20.0 Bar IS-S
Visible if PG01
> 1
PA29
C2 supply LP
alarm setpoint Circuit 2 supply probe low
pressure alarm setpoint
2.0 PH03 PA31 Bar IS-S
Visible if PG01
> 1 and PG30 =
0
PA30
C2 supply LP
alarm diff. Circuit 2 supply probe low
pressure alarm differential
0.5 0.0 20.0 Bar IS-S
Visible if PG01
> 1 and PG30 =
0
PA31
C2 supply HP
alarm setpoint Circuit 2 supply probe high
pressure alarm setpoint
20.0 PA29 PH04 Bar IS-S
Visible if PG01
> 1 and PG30 =
0
PA32
Circuit 2 supply
HP alarm diff.
.
Circuit 2 supply probe high
pressure alarm differential
1.0 0.0 20.0 Bar IS-S
Visible if PG01
> 1 and PG30 =
0
PA35
C3 suction LP
alarm setpoint Circuit 3 suction probe low
pressure alarm setpoint
0.5 PH01 PA37 Bar IS-S
Visible if PG01
> 2
PA36
C3 suction LP
alarm diff. Circuit 3 suction probe low
pressure alarm differential
0.5 0.0 20.0 Bar IS-S
Visible if PG01
> 2
PA37
C3 suction HP
alarm setpoint Circuit 3 suction probe high
pressure alarm setpoint
4.0 PA35 PH02 Bar IS-S
Visible if PG01
> 2
PA38
C3 suction HP
alarm diff. Circuit 3 suction probe high
pressure alarm differential
0.5 0.0 20.0 Bar IS-S
Visible if PG01
> 2
