C-PRO MEGA RACK & C-PRO GIGA RACK APPLICATION MANUAL
Page
45
PF13
Fan max,
setpoint
Circuit 1
Maximum supply setpoint
value pertaining to the
circuit 1 fans
25.0
SPF1
PH04
Bar
IS-RF
PF14
Fan regulation
Circuit 1
Sets the type of regulation
for controlling the circuit 1
fans
Side
Band (0)
Side
Band (0)
Neutral
Zone (1)
IS-RF
PF16
Fan integral time
Circuit 1
Integral time Ti for side
band regulation of circuit 1
fans
600
0
999
Sec
IS-RF
Visible if PF14
= 0
PF17
Fan proportional
band. Circuit 1
Proportional band Bp for
side band regulation of
circuit 1 fans
0.5
0
20.0
Bar
IS-RF
Visible if PF14
= 0
PF18
Fan zone
Circuit 1
Zone value for neutral zone
regulation of circuit 1 fans
1.0
0
20.0
Bar
IS-RF
Visible if PF14
= 1
PF20
Fan TOn/TOff
Circuit 1
Next fan insertion/release
time ( circuit 1 neutral zone
reg.)
10
0
999
Sec
IS-RF
Visible if PF14
= 1
PF24
Fan inverter
differential
Circuit 1
Differential for fan
regulation with circuit 1
inverter
0.5
0.0
20.0
Bar
IS-RF
Visible if PG42
= 1
PF25
Fan inverter SP
offset.
Circuit 1
Suction setpoint offset for
circuit 1 inverter regulation
of the fan.
0.0
-20.0
20.0
Bar
IS-RF
Visible if PG42
= 1
PF26
Fan inverter
minimum
Circuit 1
Minimum fan value with
circuit 1 inverter
0.0
0.0
100.0
%
IS-RF
Visible if PG42
= 1
PF27
Fan inverter
speedup
Circuit 1
Fan speedup time with
circuit 1 inverter
2
0
999
Sec
IS-RF
Visible if PG42
= 1
PF28
Fan inverter time
Circuit 1
Inverter ramp. Time taken
for the inverter to go from
the minimum value to the
maximum value ( circuit 1
neutral zone reg.)
10
0
999
Sec
IS-RF
Visible if PG42
= 1
PF32
Fan min. setpoint
Circuit 2
Minimum supply setpoint
value pertaining to the
circuit 2 fans
1.0
PH03
SPF2
Bar
IS-RF
Visible if PG01
> 1 and PG30 =
0
PF33
Fan max,
setpoint
Circuit 2
Maximum supply setpoint
value pertaining to the
circuit 2 fans
25.0
SPF2
PH04
Bar
IS-RF
Visible if PG01
> 1 and PG30 =
0
PF34
Fan regulation
Circuit 2
Sets the type of regulation
for controlling the circuit 2
fans
Side
Band (0)
Side
Band (0)
Neutral
Zone (1)
IS-RF
Visible if PG01
> 1 and PG30 =
0
PF36
Fan integral time
Circuit 2
Integral time Ti for side
band regulation of circuit 2
fans
600
0
999
Sec
IS-RF
Visible if PG01
> 1 and PG30 =
0 and
PF34 = 0
PF37
Fan proportional
band. Circuit 2
Proportional band Bp for
side band regulation of
circuit 2 fans
0.5
0
20.0
Bar
IS-RF
Visible if PG01
> 1 and PG30 =
0 and
PF34 = 0
