C-PRO MEGA RACK & C-PRO GIGA RACK APPLICATION MANUAL
Page
46
PF38
Fan zone
Circuit 2
Zone value for neutral zone
regulation of circuit 2 fans
1.0
0
20.0
Bar
IS-RF
Visible if PG01
> 1 and PG30 =
0 and
PF34 = 1
PF40
Fan TOn/TOff
Circuit 2
Next fan insertion/release
time ( circuit 2 neutral zone
reg.)
10
0
999
Sec
IS-RF
Visible if PG01
> 1 and PG30 =
0 and
PF34 = 1
PF44
Fan inverter
differential
Circuit 2
Differential for fan
regulation with circuit 2
inverter
0.5
0.0
20.0
Bar
IS-RF
Visible if PG01
> 1 and PG30 =
0 and
PG46 = 1
PF45
Fan inverter SP
offset.
Circuit 2
Suction setpoint offset for
circuit 2 inverter regulation
of the fan.
0.0
-20.0
20.0
Bar
IS-RF
Visible if PG01
> 1 and PG30 =
0 and
PG46 = 1
PF46
Fan inverter
minimum
Circuit 2
Minimum fan value with
circuit 2 inverter
0.0
0.0
100.0
%
IS-RF
Visible if PG01
> 1 and PG30 =
0 and
PG46 = 1
PF47
Fan inverter
speedup
Circuit 2
Fan speedup time with
circuit 2 inverter
2
0
999
Sec
IS-RF
Visible if PG01
> 1 and PG30 =
0 and
PG46 = 1
PF48
Fan inverter time
Circuit 2
Inverter ramp. Time taken
for the inverter to go from
the minimum value to the
maximum value ( circuit 2
neutral zone reg.)
10
0
999
Sec
IS-RF
Visible if PG01
> 1 and PG30 =
0 and
PG46 = 1
PF52
Fan min. setpoint
Circuit 3
Minimum supply setpoint
value pertaining to the
circuit 3 fans
1.0
PH03
SPF3
Bar
IS-RF
Visible if PG01
> 2 and PG30 =
0
PF53
Fan max,
setpoint
Circuit 3
Maximum supply setpoint
value pertaining to the
circuit 3 fans
25.0
SPF3
PH04
Bar
IS-RF
Visible if PG01
> 2 and PG30 =
0
PF54
Fan regulation
Circuit 3
Sets the type of regulation
for controlling the circuit 3
fans
Side
Band (0)
Side
Band (0)
Neutral
Zone (1)
IS-RF
Visible if PG01
> 2 and PG30 =
0
PF56
Fan integral time
Circuit 3
Integral time Ti for side
band regulation of circuit 3
fans
600
0
999
Sec
IS-RF
Visible if PG01
> 2 and PG30 =
0 and
PF54 = 0
PF57
Fan proportional
band. Circuit 3
Proportional band Bp for
side band regulation of
circuit 3 fans
0.5
0
20.0
Bar
IS-RF
Visible if PG01
> 2 and PG30 =
0 and
PF54 = 0
PF58
Fan zone
Circuit 3
Zone value for neutral zone
regulation of circuit 3 fans
1.0
0
20.0
Bar
IS-RF
Visible if PG01
> 2 and PG30 =
0 and
PF54 = 1
PF60
Fan TOn/TOff
Circuit 3
Next fan insertion/release
time ( circuit 3 neutral zone
reg.)
10
0
999
Sec
IS-RF
Visible if PG01
> 2 and PG30 =
0 and
PF54 = 1
