10 TECHNICAL DATA
10.1 Technical data
Purpose of control: operating control device.
Construction of control: electronic device to be incorporated.
Box: self-extinguishing transparent.
Size: 118.0 x 111.0 x 26.7 mm (4.645 x 4.370 x 1.051 in; L x H x P).
Mounting:
- by panel, with self-threading screws
- built-in (in box like “506e” BTicino and self-threading screws)
- by wall (in wall mounting support CPVW00 EVCO, to order separately and with
self-threading screws).
Protection rating: IP40 (IP65 in case of panel mounting with gasket 0027000007, to order separately).
Connections:
- screw removable terminal blocks (power supply, RS-485 MODBUS port and CAN
CANBUS port)
- USB connector type A (USB port).
The maximum length of the connecting cables are the following:
- power supply: 10 m (32.8 ft)
- RS-485 MODBUS port: 1,000 m (3,280 ft)
- CAN CANBUS port:
- 1,000 m (3,280 ft) with baud rate 20,000 baud
- 500 m (1,640 ft) with baud rate 50,000 baud
- 250 m (820 ft) with baud rate 125,000 baud
- 50 m (164 ft) with baud rate 500,000 baud.
According to the factory settings, the device automatically detects the baud rate of the other
elements of the network, on condition that it is one of those listed here above; on
afterwards set the baud rate to the same value of the other elements.
Working temperature: from 0 to 55 °C (from 32 to 131 °F).
Storage temperature: from -10 to 70 °C (from 14 to 158 °F).
Working humidity: from 10 to 90 % of relative humidity without condensate.
Pollution situation: 2.
