EVCO S.p.A. Vcolor | Hardware manual ver. 1.0 | Code 144VCOE104
page 16 of 38
5 FIRST USE
5.1 First use
Operate as follows:
1. Make the installation of the device with the modality shown in chapter 2 “SIZE AND INSTALLATION” following all the
additional information related in paragraph 3.7 “
2. Make the wiring diagram of the device as shown in chapter 3 “WIRING DIAGRAM” following all the additional information
related in paragraph 3.7 “Additional information for wiring diagram” without wiring the power supply.
3. Connect the power supply of the device: it will be started an internal test.
The test takes typically some seconds.
4. To the end of the internal test the display shows Checking . . .
5. Press and release the area in the bottom right-hand corner of the display: the display will show the sensitive areas.
6. Set the date and the time; look at paragraph 7.1 “Setting the date and the time”.
7. Configure the device with the procedure shown in paragraph 7.4 “Setting the configuration parameters of the menu
“Networks””.
The following table shows the meaning of the main configuration parameters; the parameters are listed with the order it is
opportune the device is configured.
PARAM. MENU MEANING
FACTORY
SETTING
MyNode Networks / CAN bus local CAN node address, or of the device 99
Network
Node
Networks / CAN bus
remote CAN nodes address, or of the other elements of the
network
- - -
Address Networks / UART
device MODBUS address (meaningful on condition that the
communication protocol is MODBUS slave)
1
Parity Networks / UART
parity of the MODBUS communication
none = none
odd = odd
even = even
even
Baudrate Networks / UART
baud rate of the MODBUS communication
1200 = 1,200 baud
2400 = 2,400 baud
4800 = 4,800 baud
9600 = 9,600 baud
19200 = 19,200 baud
28800 = 28,800 baud
38400 = 38,400 baud
57600 = 57,600 baud
9600
Bit Stop Networks / UART
number of stop bit of the MODBUS communication
1 bit = 1 bit
2 bit = 2 bit
1 bit
According to the factory setting the device works in browser modality.
For further information look at the following paragraphs.
