application managed by the K5 (K3 in the models with
direct load connection) digital output (35) (36)
0
=
reserved
1
=
DEMISTER HEATING ELEMENTS - in this case the
“AUXILIARY” key and parameter u6 will be
activated
2
=
AUXILIARY OUTPUT - in this case the “AUXILIARY”
key and parameters i5, i15 and u2 will be
activated
3
=
ALARM OUTPUTS - in this case parameter u4 will
be activated
4
=
DOOR HEATING ELEMENTS - in this case
parameter u5 will be activated
5
=
HEATING
ELEMENTS
FOR
NEUTRAL
AREA
OPERATION - in this case parameter u7 will be
activated
6
=
CONDENSER FAN - in this case parameters P4,
F11 and F12 will be activated
7
=
COMPRESSOR 2 - in this case, parameters r0,
r12, C11, C12 and C13 (37) will assume
significance of
8
=
DEFROSTING 2 - in this case parameters P4 and d
(38) will assume significance
9
=
EVAPORATOR FAN 2 - in this case parameters P4
and F (39) will assume significance of
10
=
PUMP DOWN VALVE - in this case, parameters
C14
and
u3
will
assume
significance
of
(RESERVED in models EVB1246 and EVB1256)
11
=
ON/STAND-BY - in this case “ON/STAND-BY” key
will assume significance (42)
12
=
MAN IN COLD ROOM - in this case, parameters i5
and i15 will assume significance of
