EVBOX1 | Installation guide ver. 1.3 | Code 144BOX1E134
page 65 of 92
i15
0
9
- - - -
9
9
9
9
9
9
9
9
6
=
ACTIVATION
OF
THE
MINIMUM
PRESSURE
SWITCH ALARM - the compressor will be switched
off, the display will show the flashing code “LP”
and the buzzer will be activated (until the input is
deactivated); if u1 and/or u11 = 10, the
compressor will be switched off after the switching
off of the pump down valve (also look at C14 and
i17)
7
=
COMPRESSOR THERMAL PROTECTION - the
compressor will be switched off, the display will
show the flashing code “C1t” and the buzzer will
be activated (until the input is deactivated)
8
=
COMPRESSOR 2 THERMAL PROTECTION - the
compressor will 2 be switched off (only if u1
and/or
u11 = 7), the display will show the flashing code
“C2t” and the buzzer will be activated (until the
input is deactivated)
9
=
MAN IN COLD ROOM ALARM ACTIVATION - the
man in cold room output shall be turned on (only
if u1 and/or u11 = 12), the display will show the
flashing code “MiC” and the buzzer will be
activated (until the input is deactivated)
i16
0
1
- - - -
0
0
0
0
0
0
0
0
type of multifunction 2 input contact
0
=
normally open (active input with closed contact)
1
=
normally closed (active input with open contact)
i17
0
240
s
30
30
30
30
30
30
30
30
minimum
pressure switch alarm delay after the
compressor switches on (code “LP”)
