1.2 Summary table of available models, their main characteristics and purchase
codes
The following table contains a description of the available models.
Available models
E
V
B
1
2
0
4
E
V
B
1
2
1
4
E
V
B
1
2
0
6
E
V
B
1
2
1
6
E
V
B
1
2
2
6
E
V
B
1
2
3
6
E
V
B
1
2
4
6
E
V
B
1
2
5
6
The following table shows the main characteristics of the devices.
E
V
B
1
2
0
4
E
V
B
1
2
1
4
E
V
B
1
2
0
6
E
V
B
1
2
1
6
E
V
B
1
2
2
6
E
V
B
1
2
3
6
E
V
B
1
2
4
6
E
V
B
1
2
5
6
Power supply
115... 230 VAC • • • • • • • •
Analogue inputs
room temperature (PTC/NTC/Pt 1000) • • • • • • • •
evaporator temperature (PTC/NTC/Pt 1000) • • • • • • • •
auxiliary temperature (PTC/NTC/Pt 1000) (1) • • • • • • • •
vapour pressure (4-20 mA) • •
evaporation temperature (PTC/NTC/Pt 1000) • •
Digital inputs (for NA/NC contact)
door micro switch • • • • • • • •
multifunction • • • • • • • •
multifunction 2 • • • • • • • •
Digital inputs (electromechanical relays; A res. @ 250 VAC)
compressor 30 A 30 A 30 A 30 A 30 A 30 A 30 A 30 A
defrosting 16 A 16 A 16 A 16 A 16 A 16 A 16 A 16 A
evaporator fan 30 A 30 A 30 A 30 A 30 A 30 A 30 A 30 A
room light 16 A 16 A 16 A 16 A 16 A 16 A
load 4 (default to room light) (2) 8 A 8 A
