60 Device Configuration
Device Advisor Driver Messages
- Loaded OK/Total indicates the ratio of successful loads to load attempts.
The rightmost, or Total, number indicates the number of times the system
tried to load NS-Link, while the left most number indicates the number of
times that NS-Link activated successfully after loading. Ideally, these two
numbers should be the same.
- Devices Detected/Avail indicates the number of NS-Link devices currently
attached to the network, and the number of devices currently available to
be acquired by this server.
For example, if you have one device installed, and it is not currently
configured on any server, then the value displayed is 1/1. But if you have
one device installed, and it is currently configured on a server, then the
value displayed is 1/0.
Device Advisor
Driver Messages The following tables provide information about device driver summary messages
and reported state messages.
Message Description
Active
The normal state for NS-Link device that is
attached to a server and is ready for data traffic.
Cannot detect any NS-Link.
Network traffic is being received, but not from a
NS-Link device. Check the network connections
and verify that the NS-Link device is powered up.
Cannot detect network
No inbound traffic of any sort NS-Link device may
be inoperative or you may have a network cabling
problem.
Cannot detect NS-Link with
specified MAC address.
Network traffic is being received from a NS-Link
device, but not the one specified in the Network
Connection tab. Check the device to make sure
that you are using the correct MAC address and
check the General tab to verify that you are
working with the correct device.
Connect
The server has completed the download and is
completing initialization.
Counts reset.
This message displays immediately after you click
the Reset button.
Init
This is the normal state for undetected and
inactive NS-Link device.
InitOwn
The server has acquired the NS-Link device but
has not downloaded the control software.
Invalid
An illegal NS-Link device state has been detected.
Reset the NS-Link device.
Not found
The specified MAC address is not configured on
this server.
NS-Link active.
Normal state: the NS-Link device is installed
correctly and active with data traffic.
NS-Link detected,
initializing.
The server has acquired the NS-Link device and is
downloading the control program. The device will
be available shortly.
NS-Link device detected and
configured for this server, but
is not yet assigned to this
server. Either the NS-Link device is currently being
controlled by another server or the device power
has been cycled and the device is waiting for a
server to acquire it.
