3. OPERATION
3.1 INTRODUCTION
The information in this Chapter provides a guide to the operation of the ACS using the controls
and display mounted on the front panel of the unit. This Chapter describes the basic procedure
to navigate through the extensive array of menus and options incorporated in the ACS design.
Descriptions for all menus and options are also provided.
3.2 FRONT PANEL OPERATING CONTROLS AND DISPLAYS
The front panel of the ACS contains an vacuum fluorescent display (VFD) and an 8-key touch-
pad. The display and controls are illustrated and described in Figure 3-1 and Table 3-1
respectively.
Figure 3-1: ACS Front Panel Controls and Displays
1
6
2
3 5
4
