MC2: 04/23/13 Page 119 of 144

GF-131

AERCO Control System (ACS)

AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 • Phone: 800-526-0288

Installation, Operation, and Maintenance Manual

OMM-0081_0D

5. You are now ready to execute this command on the remote machine, simply click

the

Open button at the bottom of the dialog.

6. You will have to provide an account name and password in the terminal window to

complete the process.

G.3 RS232 COMMUNICATION SET-UP

Regardless of the terminal emulation utilized, the following guidelines must be adhered to when

interfacing the ACS to the Terminal device:

1. Connect cable leads to the RS-232 connector in the wiring area of the ACS.
2. Connect the free end of the cable to the COM 1 or COM 2 port on your laptop, or other

suitable terminal device.

3. Set up the emulator communication link as follows:

a. Set the baud rate to 9600.
b. Set the data format to 8 bits, 1 stop bit, no parity and either Xon/Xoff or No Flow

Control.

4. Turn on the ACS by pressing the ON/OFF key. Verify that the ON LED lights.
5. Press the MENU key. Go to the SETUP MENU and enter a valid PASSWORD.
6. Press the MENU key and go to the RS232 MENU.
7. Press the ▲ arrow key to display the RS232 MODE option.
8. Press the ▲ or ▼ arrow key to display NORMAL. Press the ENTER key to store the

NORMAL selection

9. Start the emulator software program.
10. At the command prompt, enter the password EXACTLY as follows (case-sensitive):

P=gobms

11. Press Return () on your terminal.
12. The setup is now complete. You are ready to begin viewing or changing ACS functions.

G.4 PROGRAMMING PROCEDURE

ACS functions which can be viewed or changed are listed in

Table G-1 along with their

corresponding command numbers. Functions which can only be viewed (such as actual sensor

readings) are marked “Read Only”. Viewing or changing function values is accomplished as

follows:

1. Select the number of the desired command from Table J-1.
2. To view a parameter, type ?, followed by the command number and then press return

(). For example, to view command no. 00 (HEADER TEMPERATURE), enter:

?00

The header temperature reading will be displayed. All temperature readings are in °F.

3. To program (set) a ACS parameter, type @, followed by the command number, an equal

sign, the parameter value and a trailing zero. For example, to set command 05

(SYSTEM OUTSIDE AIR START TEMPERATURE) to 65°F, enter:

@05=650

Use the above steps to view and/or program the desired ACS functions listed in

Table G-1.
