84 Chapter 5
•
•
•
•
•
•
On the HI 6510 series instrument display, select the communication menu and use the
UP or DOWN button to select the 4-20mA submenu, then select the Value 20mA menu
item. The current value will be displayed, press the ENTER or the RIGHT button if this
value needs to be modified.
NOTE The analog output is not isolated. A 4-20mA isolator may be required for stable readings
depending on ground conditions.
Diagnostics Parameter Menu
Diagnostics is covered extensively in Troubleshooting (Chapter 9).
The available parameters on the Web page are:
• Parameters (which shows all parameters on the instrument)
• Integrated Technician (when connected to an IT Junction Box)
• C2
• Stability test 
The available parameters on the device are:
• Stability test
• Weight and Voltage
See the Chapter 9 for further information on Diagnostics.
Display Parameter Menu
The following sets of parameters are only active from the display panel when the display
panel is attached to the instrument. They are not enabled on the Web Page.
• Backlight
• Power Saving
• Set Background
• Set Foreground
• Split Screen
WARNING - THE HI 6510 ANALOG 4 TO 20mA IS AN OUTPUT SOURCE.
DO NOT CONNECT THE 4 TO 20mA OUTPUT TO ANOTHER INTERNAL
OR EXTERNAL ANALOG SOURCE. TO DO SO MAY RESULT IN
PROPERTY DAMAGE AND/OR PERSONAL INJURY.
AVERTISSEMENT – Le HI 6510 analogiques 4 à 20 mA est une source de sortie.
Ne pas brancher la sortie 4 à 20 mA à l'autre Source analogique interne ou
externe. Pour ce faire peut entraîner des dommages matériels et / ou corporels.
