5) Slide the breech extension into the receiver
making sure that the barrel ring slides on the
magazine tube (fig. 7).
6) Push the barrel-breech assembly all the way
in (fig. 8) until it clicks into place and is firmly
seated.
NOTE: make sure that the breech extension does
not collide against the bolt locking head but
rather that it fits between the cover and the lock-
ing head.
7) Slide the fore-end over the magazine tube
(fig. 9).
8) Screw the fore-end cap on to the end of the
magazine tube and tighten it sufficiently to
hold the barrel and fore-end securely against
the receiver (fig. 10).
NOTE: always make sure that the cap spring is
inserted in the cap itself (fig. 10) before locking
the barrel and fore-end to the receiver: a missing
spring will not allow proper locking of the barrel,
causing serious damage to the shotgun.
9) Press the carrier button to close the bolt (fig.
11).
Gun safety catch
Press the safety button on the trigger guard until
its red ring, indicating firing position, is no lon-
ger visible (fig. 12).
39
7
8
9
10
12
11
