Method for Fixing the Rear of the Unit

(a) Using the Rear Support Strap

(D ^

(M6)

V

Drill a hole 6.5 to 7 mm
in diameter. --------------

(D

Washer Assembling Hex.

Bolt (M6 x20 mm)

CD

Rear Support Strap

Fire wall ot car

(7)

Washer

Assembling

Hex. Bolt
(M5 X 10 mm)*1

Display Unit

'1: Use M5 X 8 mm size bolt (optional) if bolts other than

the supplied ones are to be used.
