Hide-away Unit
General
Power supply
Current consumption
Maximum power output
Compatible speaker impedance
Video input signal
Audio input sensitivity
Video output signal
Pre-Amp output voltage
Pre-Amp output impedance
Dimensions (VI/ x H x D)
Weight
FM stereo radio
Frequency range
Usable sensitivity
Stereo separation
S/N ratio
12 V DC (11 V -16 V), test voltage 14.4 V, negative ground
Less than 10 A (during disc playback)
45Wx4ch + 35W(at16V)
4 a
Composite video signal, 1.0 Vp-p (75 Q.)
2 Vrms
Composite video signal, 1.0 Vp-p (75 a)
4 Vrms
Less than 60 Q
9-5/8”
X 1-5/8” X 5-7/8" (245 x 42 x 150 mm)
3lbs. 16oz. (1.8 kg)
87.9- 107.9 MHz
12dBf
35 dB (1 kHz)
70 dB
AM stereo radio
Frequency range
Usable sensitivity
Image rejection ratio
Video section
Signal format
Video output
Region number
Audio section
Output voltage/Impedance
Frequency characteristics
(when "LARGE” is selected)
Front L/R, Center, Rear (surround) L/R
Delay time
Dolby Digital
Center
Rear (surround) L/R
Dolby Pro Logic
Rear (surround) L/R
Distortion
Front L/R (1 kHz, 0 dB, PCM input)
Dynamic range
S/N ratio
530- 1 710 kHz
28 dB/pV
50 dB
NTSC (Standard signal format in U.S and Japan)
75 a, 1 Vp-p
1 and ALL
4 Vrms/60 Q
20 Hz-20 kHz (±1 dB)
0 - 5 ms
0 -15 ms
15 - 30 ms
0.01 %
96 dB (during CD playback and connected with optical fiber cable)
100 dB (during CD playback and connected with optical fiber cable)
Above specifications comply with EIA standards.
Note: Specifications and the design are subject to modification without notice due to improvements in technology.
