Nortel Secure Router 8000 Series
Configuration Guide - Basic Configuration 2 Configuration environment setup
2.4.3 Initializing and configuring the modem on the interface
Do as follows on the router:
Step 1 Configure the authentication mode of logon users.
Step 2 Configure the authority limitation of logon users.
For more information, see Nortel Secure Router 8000 Series Configuration - Security
(NN46240-600).
—End
2.4.4 Configuring the connection between the remote terminal
and the router
Do as follows on the terminal PC:
Step 1 Run a terminal emulation program on the PC (such as Windows XP HyperTerminal) to enter
the Connection Description window.
Step 2 Enter the connection name of the PC and the router, such as Dial.
Step 3 Click OK to enter the Connect To window.
Step 4 Enter the parameters and select options as required.
Step 5 Click OK to enter the Connect window.
Step 6 Click Dial.
—End
2.4.5 Logging on to the router
In the logon window, enter the user name and password.
After configuration, a command line prompt such as
N o r t e i
appears. Enter the configuration
environment in the user view.
2.5 Configuration examples
2.5.1 Example of logging on through the console port
Networking requirements
Initialize the configuration of the router when the router is powered on for the first time.
Issue 5.3 (30 March 2009) Nortel Networks Inc. 2-7
