Nortel Secure Router 8000 Series
Configuration Guide - Basic Configuration
8 FTP, TFTP, and Xmodem
[ f t p ]
get vrpv5r3d031.cc
[ f t p ]
quit
—End
8.9.4 Example of configuring TFTP
Networking requirements
As shown in Figure 8-4, the IP address of the TFTP server is 10.111.16.160/24.
Log on to the router from the HyperTerminal and then download the file vrp.cc from the
TFTP server.
Figure 8-4 Using TFTP to download files
m
■
m
mzm
TFTP Server
10.111.16.160/24
Quidw ay
PC
Configuration roadmap
1.
Run the TFTP software on the TFTP server.
2.
Configure the position of the source file on the server.
3.
Use the TFTP command on the Nortel router to download the files.
Data preparation
To complete the configuration, you need the following data:
•
TFTP software installed on the TFTP server
•
path of the source file on the TFTP server
•
destination file name and its path on the Nortel router
Configuration procedure
Step 1 Start the TFTP server and configure its base directory as the directory where the vrp.cc file
resides. Figure 8-5 shows the interface.
Issue 5.3 (30 March 2009)
Nortel Networks Inc.
8-27
