Port Information 9145EMP NID Software User’s Manual
Link Aggregation
73
5.6.1.2 LAG Aggregation Ports
To configure aggregation ports, from the LAG Configuration screen (Figure 5-18), type 2 and
press Enter. The LAG Ports List (Figure 5-20) opens.
Figure 5-20 LAG Ports List screen
Follow the instructions at the bottom of the screen to edit attributes and view debug information.
Press Esc to return to the Port Information screen.
• To view debug information, type D and press Enter. The first port is highlighted. Press the
Space bar to scroll through the list. When the port you wish to view is highlighted, press
Enter. The LAG Port Debug Information screen opens (Figure 5-21). This screen is infor-
mational only. Press Esc to return to the LAG Ports List.
NOTE: Debug information is for LAG debug procedures mandated by the IEEE 802.3ad stan-
dard, not Canoga Perkins specific system debug information.
Canoga Perkins Corp. Ethernet Network Interface Device 21-MAR-2011
9145EMP-761-4-0 V40.43 Canoga 9145EMP 32 device 11:20:59
--------------------------------LAG PORTS LIST---------------Display 1 - 2 of 2-
INTERFACE ADMIN STATUS AGGREGATION STATUS OPERATIONAL STATUS
NET1 Disabled Not assigned Down
NET2 Disabled Not assigned Down
Select (E)dit, (D)ebug, ESC to return:
------------------------------------Messages-----------------------------------
