CoS Configuration 9145EMP NID Software User’s Manual
CoS Queues Configuration
115
10.3.2.1 IP Precedence Mode
On the User Port Untagged Packet Classifier Mapping screen (Figure 10-8) for IP Precedence:
1. Type the number of the IP Precedence (or a range of numbers), and press Enter. The
CoSQ setting in the column beside the IP Precedence number is highlighted.
2. Press the Space bar to scroll through the available queues.
3. Select a queue and press Enter. (Only a queue that is enabled can be selected. To
enable or disable a queue, see “Queues Configuration on Network Ports” on page 119.)
4. Press Esc to return to the User Port Untagged Packet Classifier Configuration screen.
Figure 10-8 User Port Untagged Packet Classifier Mapping screen (IP Precedence mode)
Canoga Perkins Corp. Ethernet Network Interface Device 21-MAR-2011
9145EMP-761-4-0 V40.43 Canoga 9145EMP 32 device 11:20:59
---------------- USER PORT UNTAGGED PACKET CLASSIFIER MAPPING ------------------
Mode: IP Precedence Mode
IP Precedence CoSQ
------------- ----
0 Q1
1 Q1
2 Q1
3 Q1
4 Q2
5 Q2
6 Q3
7 Q3
Select IPP or a Range x-y [0-7]:
------------------------------------Messages-----------------------------------
