9145EMP NID Software User’s Manual Configuring EVC
EVC Configuration
192
Figure 12-9 P-Bit Translation Table screen
14. To modify CVID to T-Tag PCP Mapping, type 12 and press Enter. The C-VLAN to T-Tag
PCP Map screen (Figure 12-10) opens.
NOTE: This screen is available only if T-Tag PCP mapping is set to C-VLAN. By default, any
VLAN in the EVC is assigned to PCP 0. If the T-Tag PCP mapping mode is changed, the config-
uration record will be reset to default values.
• To modify the mapping, type M and press Enter. You are prompted to enter a C-
VLAN ID.
• You can search for specific C-VLAN by ID number. See the Find instructions at
the bottom of your screen.
• Press Esc to return to the Modify EVC Configuration Record screen.
Canoga Perkins Corp. Ethernet Network Interface Device 21-MAR-2011
9145EMP-761-4-0 V40.43 Canoga 9145EMP 32 device 11:20:59
---------------------------P-BIT TRANSLATION TABLE-----------------------------
S-VLAN ID: 1 Port: USER1
Ingress Port: User
Egress Port: Network
-------
1) Incoming P-Bit 0 translated to 0
2) Incoming P-Bit 1 translated to 1
3) Incoming P-Bit 2 translated to 2
4) Incoming P-Bit 3 translated to 3
5) Incoming P-Bit 4 translated to 4
6) Incoming P-Bit 5 translated to 5
7) Incoming P-Bit 6 translated to 6
8) Incoming P-Bit 7 translated to 7
Select [1-8] or CTRL-T to switch direction :
------------------------------------Messages-----------------------------------
