9145EMP NID Software User’s Manual Bandwidth Profiling
User to Network Egress Shapers
210
13.7 User to Network Egress Shapers
You can view and edit user to network egress shapers. Each queue, identified by a queue> pair, can be assigned (or unassigned) to one shaper.
13.7.1 Viewing the Shapers List
1. On the Bandwidth Profile Enforcement screen (Figure 13-1), type 4 and press Enter. The
Egress Shapers List screen (Figure 13-8) opens.
Figure 13-8 Egress Shapers List screen
13.7.2 Modifying a Shaper
1. On the Egress Shapers List screen (Figure 13-8), type the number of the shaper you
wish to modify and press Enter. The Egress Shaper Configuration screen (Figure 13-9)
opens.
2. To change the bandwidth profile, type 1. Press the Space bar to select Best Effort or
None, and press Enter.
3. To enable or disable the shaper, type 2. Press the Space bar to select Enable or Disable,
and press Enter.
4. To assign a queue to a shaper, type i and press Enter. A specific queue can be assigned
to one shaper only.
Canoga Perkins Corp. Ethernet Network Interface Device 21-MAR-2011
9145EMP-761-4-0 V40.43 03:29:52
-----------------------------EGRESS SHAPERS LIST-------------------------------
Shaper Shaper BW Profile Status Number of queues
1 Best Effort Disabled 4
2 None Disabled 0
3 None Disabled 0
4 None Disabled 0
5 None Disabled 0
6 None Disabled 0
7 None Disabled 0
8 None Disabled 0
9 None Disabled 0
10 None Disabled 0
11 None Disabled 0
12 None Disabled 0
13 None Disabled 0
14 None Disabled 0
15 None Disabled 0
16 None Disabled 0
Select shaper[1-16]:
------------------------------------Messages-----------------------------------
