Port Information 9145EMP NID Software User’s Manual
51
Chapter 5
Port Information
5.0 Port Description
The Port Information screen (Figure 5-1) provides a description and a graphic depiction of the
User, Network, Multipurpose and Management ports for the 9145EMP, with options to view
parameters and statistics for specific ports. Configuration information includes the model number,
description, and revision, as well as the serial number; and link, remote fault, and physical status
and settings.
Figure 5-1 Port Information screen
Canoga Perkins Corp. Ethernet Network Interface Device 21-MAR-2011
9145EMP-761-4-0 V40.43 Canoga 9145EMP 32 device 11:20:59
--------------------------------PORT INFORMATION ------------------------------
____________________________________________________________________________
| LA_SPD LA_SPD Canoga |
||o o| |o o| MGMT UTP Perkins |
|| UTP | o o o o o o o o | UTP | o o o o _____ |
|| 2|LA SPD LA SPD LA SPD LA SPD| 4|LA SPD LA SPD | | o LNK/ACT |
||______| 1 2 3 4 |______| 1 2 |_____| o SPD |
|| 1|___________________________| 3|_____________ |
|| UTP |off |off |off |off | UTP | |off | _______ G POWER |
||o o| SFP | SFP | SFP | SFP |o o| SFP | SFP | \:::::/ o STATUS |
||LA_SPD|______|______|______|______|LA_SPD|______|______| |
| USER PORTS NETWORK PORTS 9145EMP-761-0-|
|____________________________________________________________________________|
1) Link Status 4) Layer 2 Statistics
2) Port Configuration 5) RMON Group 1 Statistics
3) Network side Configuration 6) Link Aggregation
Select [1-6]:
------------------------------------Messages-----------------------------------
