Advanced Guide > About Network Communication > Changing and Confirming Network Settings > Printing Out Network
Setting Information
Printing Out Network Setting Information
You can print out the network settings of the machine such as its IP address and SSID.
Important
This print out contains valuable information about your computer. Handle it with care.
1. Make sure that the machine is turned on.
2. Load a sheet of A4 or Letter-sized plain paper in the Cassette.
3. Select Settings on the HOME screen, then press the OK button.
4. Select Device settings, then press the OK button.
5. Select LAN settings, then press the OK button.
6. Select Confirm LAN settings, then press the OK button.
7. Select Print LAN details, then press the OK button.
8. Select Yes, then press the OK button.
The following information on the machine's network setting is printed out.
Item Explanations of the item Setting
Wireless LAN Wireless LAN Enable/Disable
Link Status Status of the Wireless LAN Active/Inactive
MAC Address MAC Address XX:XX:XX:XX:XX:XX
SSID SSID SSID of the wireless LAN
Connection Mode Connection Mode Infrastructure
Channel Channel XX (1 to 13)
Encryption Method of the Encryption none/WEP/TKIP/AES
WEP Key Length WEP Key Length Inactive/128/64
Authentication Method of the Authentication auto/open/shared/WPA-PSK/WPA2-PSK
Signal Strength Signal Strength 0 to 100 [%]
TCP/IP Version TCP/IP Version IPv4/IPv6
IP Address Selected IP Address XXX.XXX.XXX.XXX
Default Gateway Default Gateway XXX.XXX.XXX.XXX
Subnet Mask*1 Subnet Mask XXX.XXX.XXX.XXX
Subnet Prefix
Length*2
Subnet Prefix Length XXX
IPsec*3 IPsec setting Active
Security Protocol*3 Method of the Security Protocol ESP/ESP & AH/AH
Printer Name Printer name Printer name (Up to 15 characters)
