Page 67

Table 7-4. Print Format Commands Continued

Command

Description

Report Total Tare

Report Total Net

Report Start Date (used for summary reports)

Report End Date (used for summary reports)

Subtotal Gross

Subtotal Net

Subtotal Tare

Truck Modes

Advance Mode Default Print Formats

Table 7-5 shows the default print formats for ADVANCE mode. All print formats are, by default, set to port 4.
Use

Revolution III

or serial commands to view and edit print formats (see Section 6.3 on page 55)

Important

The AUXFMTs are automatically set up when Advanced Truck Mode is selected. To revert back to
default the unit must be reset using the RESETCONFIGURATION function. See Section 10.1.3 on
page 87 for help using RESETCONFIGURATION. If Revolution is used then the file will also have the
AUXFMTs set for Advance Truck formats so they should be reviewed before a download if they are not
as needed.

Format

Default Format String

AUXFMT.FMT#1

ID: SERIAL NUMBER: INBOUND WEIGHT:
IN:
AUXFMT.FMT#2
ID: SERIAL NUMBER: TRUCK TYPE:
DELIVERY NUMBER: DELIVERY WGT.: CUSTOMER:
SOURCE: MATERIAL:
GROSS: TARE: NET:
IN: OUT: COMMENTS:
AUXFMT.FMT#3
PRINTING TIME & DATE: VEHICLE NO. VEHICLE TYPE
MATERIALPLACEGROSS WT. TIME & DATE INSERIAL NO. DELIVERY
NO. PARTYDELIVERY WGTOUT
AUXFMT.FMT#4

AUXFMT.FMT#5
~ - GROSS WEIGHING
FIRST
AUXFMT.FMT#6
FOR THE PERIOD : TO PRINTING TIME & DATE :
AUXFMT.FMT#7
SL. SOURCE IDMATERIAL ID VEHICLE NUMBER WEIGHING NET WEIGHTNO.
SOURCE NAMEMATERIAL NAME DATE & TIME (KG)CHALLAN NUMBER
AUXFMT.FMT#8
SL. CUSTOMER IDMATERIAL ID VEHICLE NUMBER WEIGHING NET WEIGHTNO.
CUSTOMER NAME MATERIAL NAME DATE & TIME (KG)CHALLAN NUMBER
AUXFMT.FMT#9
SL. MATERIAL IDCUSTOMER ID VEHICLE NUMBER WEIGHING NET WEIGHTNO.
MATERIAL NAMECUSTOMER NAME DATE & TIME (KG)CHALLAN
NUMBER
AUXFMT.FMT#10

AUXFMT.FMT#11

Table 7-5. Default Print Formats for Advanced Truck
