KMC Controls MEP-455 Series - Manual (Page 7)

Document No. 129-361
Installation Instructions
August 3, 2004
Dimensions
Figure 10. Dimensions of the MEP-455 ControlSet Actuator and Mounting Bracket in Inches (Millimeters).
min. 8 in.
200 mm
3-3/8 in.
86 mm
MAX
3/4 in.
20 mm
1-1/8 in.
28 mm
3-1/16 in.
78 mm
7-3/4 in.
197 mm
1 in.
25 mm
11-13/16 in.
300 mm
3-15/16 in.
100 mm
1-11/32
34 mm
1-11/32
34 mm min. 2-1/2 in.
60 mm
5/32 in.
4 mm
10 mm
11/32 in.
OPENING
FOR 3/8"
FLEX CONDUIT
(3 PLS)
1-23/32 in.
30 mm
min. 1/4 in.
7 mm
min. 4 in.
100 mm
1.1 in.
28.5 mm
EA1087R1
25/32 in
20 mm
EA0249R2
9 in
230 mm
Information in this publication is based on current specifications. The company reserves the right to make changes in specifications and models as design
improvements are introduced. ControlSet is a registered trademark of KMC Controls. Other product or company names mentioned herein may be the trademarks
of their respective owners. © 2004 Siemens Building Technologies, Inc.
KMC Controls Document No. 129-361
19476 Industrial Drive
New Paris, IN 46553 Country of Origin: US
Page 7 of 7
.
Note to page 6 added on 01/11
