KMC Controls BAC-4000 Series - Manual (Page 4)

AppStat for Heat Pump Units 4 919-019-03C
Maintenance
Remove dust as necessary from the holes in the top
and bottom. Clean the display with soft, damp cloth
and mild soap.
Specifications
AppStat specifications are subject to change without
notice.
Supply Voltage 24 volts AC (–15%, +20%),
50-60 Hz, 12 VA,
Class 2 only
Inputs 0–12 volts DC with internal 10kΩ
pull-up resistors
Relay outputs SPST, 24 volts, 1 amp AC or DC
Maximum for all relay outputs is
3 amps
Analog outputs Short protected 10mA 0–12 VDC
Environmental
limits Operating 34 to 125° F (1.1 to
51.6° C)
Shipping –40 to 140° F
(–40 to 60° C)
Humidity 0 to 95% RH
(non-condensing)
Regulatory UL 916 Energy Management
Equipment
FCC Class A, Part 15, Subpart B
and complies with Canadian
ICES-003 Class A
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
Installation accessories
The following accessories are available from KMC
Controls, Inc.
XEE-6111-040 Single-hub 120 volt power
transformer
XEE-6112-040 Dual-hub 120 volt power
transformer
XEE-6311-075 120/240/277/480VAC, 24 VAC, 75 VA
transformer
HMO-10000W White mounting plate kit for retrofit
on horizontal boxes or 4 x 4 handy
boxes
Additional resources
The latest support files are always available on the
KMC Controls web site.
For detailed specifications, installation, operating ,
application, and system integration information, see
The Installation, Operation, and Application Guide
for AppStat
.
For additional specifications information, see the
BAC-4000 AppStat Data Sheet .
Important Notices
The material in this document is for information
purposes only. The contents and the product it
describes are subject to change without notice. KMC
Controls, Inc. makes no representations or
warranties with respect to this document. In no
event shall KMC Controls, Inc. be liable for any
damages, direct or incidental, arising out of or
related to the use of this document.
