Please make sure that stacking/fanout not configured for Diagnostics
execution.
Also reboot/online command is necessary for normal operation after the
offline command is issued.
Proceed with Offline [confirm yes/no]:yes
Dell#
2. Confirm the offline status.
EXEC Privilege mode
show system brief
Dell#show system brief
Stack MAC : 00:1e:c9:de:03:7b
-- Stack Info --
Unit UnitType Status ReqTyp CurTyp
Version Ports
----------------------------------------------------------------------------
--------
0 Management offline PE-FN-410S-IOA PE-FN-410S-IOA
1-0(0-1862) 12
1 Member not present
2 Member not present
3 Member not present
4 Member not present
5 Member not present
Dell#
Trace Logs
In addition to the syslog buffer, the Dell Networking OS buffers trace messages which are continuously
written by various software tasks to report hardware and software events and status information.
Each trace message provides the date, time, and name of the Dell Networking OS process. All messages
are stored in a ring buffer. You can save the messages to a file either manually or automatically after
failover.
Auto Save on Crash or Rollover
Exception information for MASTER or standby units is stored in the flash:/TRACE_LOG_DIR directory. This
directory contains files that save trace information when there has been a task crash or timeout.
• On a MASTER unit, you can reach the TRACE_LOG_DIR files by FTP or by using the show file
command from the flash://TRACE_LOG_DIR directory.
• On a Standby unit, you can reach the TRACE_LOG_DIR files only by using the show file command
from the flash://TRACE_LOG_DIR directory.
NOTE: Non-management member units do not support this functionality.
Example of the dir flash: Command
Dell#dir flash://TRACE_LOG_DIR
Directory of flash:/TRACE_LOG_DIR
1 drwx 4096 Jan 17 2011 15:02:16 +00:00 .
2 drwx 4096 Jan 01 1980 00:00:00 +00:00 ..
3 -rwx 100583 Feb 11 2011 20:41:36 +00:00 failure_trace0_RPM0_CP
Debugging and Diagnostics 271
