Fields Description
Application Priority TLV: Local ISCSI Priority Map Priority bitmap used by local DCBx port in ISCSI
advertisements in application priority TLVs.
Application Priority TLV: Remote FCOE Priority
Map Priority bitmap received from the remote DCBX
port in FCoE advertisements in application priority
TLVs.
Application Priority TLV: Remote ISCSI Priority Map Priority bitmap received from the remote DCBX
port in iSCSI advertisements in application priority
TLVs.
PFC TLV Statistics: Input TLV pkts Number of PFC TLVs received.
PFC TLV Statistics: Output TLV pkts Number of PFC TLVs transmitted.
PFC TLV Statistics: Error pkts Number of PFC error packets received.
PFC TLV Statistics: Pause Tx pkts Number of PFC pause frames transmitted.
PFC TLV Statistics: Pause Rx pkts Number of PFC pause frames received.
Input Appln Priority TLV pkts Number of Application Priority TLVs received.
Output Appln Priority TLV pkts Number of Application Priority TLVs transmitted.
Error Appln Priority TLV pkts Number of Application Priority error packets
received.
Example of the show interface ets summary Command
Dell# show interfaces te 0/1 ets summary
Interface TenGigabitEthernet 0/1
Max Supported TC Groups is 4
Number of Traffic Classes is 8
Admin mode is on
Admin Parameters :
------------------
Admin is enabled
TC-grp Priority# Bandwidth TSA
0 0,1,2,3,4,5,6,7 100% ETS
1 0% ETS
2 0% ETS
3 0% ETS
4 0% ETS
5 0% ETS
6 0% ETS
7 0% ETS
Priority# Bandwidth TSA
0 13% ETS
1 13% ETS
2 13% ETS
3 13% ETS
4 12% ETS
5 12% ETS
6 12% ETS
7 12% ETS
Remote Parameters:
Data Center Bridging (DCB) 49
