L EGEND
1 The colored squares indicate which reservoirs to fill and specify the
appropriate liquids.
2 The wells are color-coded to correspond to the reagents specified in the
reagent block instructions. The colors match the color of the bottle
covers of the reagents.
3 Routine name
4 Instructions on which liquids and reagents are required, any preparation
required, and the amounts of the liquids and reagents to use.
5 Calibration or verification kit lot numbers
6 Reagent lot numbers
7 Description of the routine. Click the arrow to show or hide the description.
Setting Up the Reagent Block
User Guide | 65
There is a diagram of the MAGPIX reagent block and well strip.
Important: The reservoirs and wells in the diagram correspond to those in the
MAGPIX reagent block and well strip as seen when you stand facing the
ejected plate.
When you select a maintenance routine, one or more reservoirs and wells are filled
in.
The Reagent Block section displays the lot number of the calibration kit and
verification kit currently selected. It also displays the lot numbers of the reagents
that belong to the calibration and verification kits. Use this information to ensure
that you are using the correct reagents.
Important: Do not mix reagents from different verification kits. All of the
reagents must belong to the same lot.
If you select a different kit from the Select Kit section, the lot information in the
Reagent Block section automatically updates with the new kit information.
