Running the Protocol
User Guide | 31
Reading the Plate
In the template diagram in the Create/Run Protocols view, the blue wells indicate
which wells have been formatted. Only formatted wells are read. Each well is read in
turn, from top to bottom, then from left to right. A pulsing triangle shows you which
well is currently being read.
Run commands status
Template diagram
Well E2
Protocol name
The Run Commands status displays information about the well that is currently
being read. In the preceding example, Well E2 is being read. The Run Commands
status indicates when the reading begins and ends for the current well.
