# Setup Name Description Options
Factory
Default
69. Meter: Peak Hold Time
Adjusts the duration for which the
peak LED stays illuminated. 0 to 5 seconds adjustable in increments of
.1 sec
0 seconds
70.
Meter: Input Peak Thresh-
old Sets the level in which the Input
Activity Ring LEDS will illuminate red. Selectable from -1 to -20 dBFS in 1 dB incre-
ments
-3 dBFS
71.
Meter: Input LED Ring
Mode
Enables or disables Input Activity
LEDs by color. Applies to the Front
Panel Ring LEDs and CL-Accessory
Input Activity LEDs. • Red and Green enabled
• Red only enabled
• Green only enabled
• Red and Green Off
Red and Green
enabled
72. Meter: Stealth Mode
Enables the LEDs to toggle On and
Off with the LCD BACKLIGHT. • Off
• On
Off
73. Meter: Track Arm LED’s
Toggles the blinking behavior of the
track arm LED’s. Armed status is indi-
cated by a solidly lit LED and Enabled
status is indicated by a blinking LED.
• Show Arm/Enable Status
• Show Arm Status Only Show Arm/Enable
Status
74. HP: Rotary Switch Function
Selects the function activated when
the Rotary Switch is pressed in while
in Record and Playback.
• Disabled:
pressing in on the switch, makes no change
to the headphone matrix.
• Selects Favorite Mode:
in Record and Playback, pressing in on the
switch will change the headphone source
immediately to the favorite selected in HP:
Favorite Mode.
• Playback Drive Select
pressing in on the switch toggles between
the available storage media for Playback.
Selects Favorite
Mode
75. HP: Monitor Modes
Selects the modes and the sequence
in which they appear in the Head-
phone Source Display.
• Inputs 1,2
• Inputs 3,4
• Inputs 5,6
• Inputs 7,8
• Tracks L,R
• Tracks A,B
• Tracks C,D
• Tracks E,F
• Tracks G,H
• Tracks X1,X2
• Input 1
• Input 2
• Input 3
• Input 4
• Input 5
• Input 6
• Input 7
• Input 8
• Track L
• Track R
• Track A
• Track B
• Track C
• Track D
• Track E
• Track F
• Track G
• Track H
• Track X1
• Track X2
• Inputs 1,2 (MS)
• Inputs 3,4 (MS)
• Inputs 5,6 (MS) • Inputs 7,8 (MS)
• Tracks L,R (MS)
• Tracks A,B (MS)
• Tracks C,D (MS)
• Tracks E,F (MS)
• Tracks G,H (MS)
• Tracks X1,X2 (MS)
• Inputs 1-4
• Inputs 1-6
• Inputs 1-8
• Tracks LA, RB
• Tracks LAC, RBD
• Tracks LACE, RBDF
• Tracks LACEG,RBDFH
• Tracks
• LACEGx1,RBDFHx2
• Tracks LRAB
• Tracks LRABCD
• Tracks LRABCDEF
• Tracks LRABCDEFGH
• Tracks LRABCDE
• GHX1X2
• Tracks LR
• Tracks LRA
• Tracks LRB
• Tracks LRC
• Tracks LRD
• Tracks LRE
• Tracks LRF
• Tracks LRG
• Tracks LRH
• Tracks LRX1
• Tracks LRX2
• Input B-format stereo
• Track B-format stereo
1) Tracks L,R
2) Tracks X1,X2
3) Tracks L
4) Tracks R
5) Tracks A
6) Tracks B
7) Tracks C
8) Tracks D
9) Tracks E
10) Tracks F
11) Tracks G
12) Tracks H
13) Tracks X1
14) Tracks X2
15) Tracks
LRABCDEF-
GHX1X2
16) Inputs 1,2
17) Inputs 3,4
18) Inputs 5,6
19) Inputs 7,8
20) Input 1
21) Input 2
22) Input 3
23) Input 4
24) Input 5
25) Input 6
26) Input 7
27) Input 8
28) Inputs1-8, 1-8
