Mode Ring LED 788T LCD
Display
Encoder
Turn
Encoder
Press
Encoder Press
and Hold
Phantom
(User Mode) Metering (PFL + Post-EQ)
Input Solo (yellow)
Input Mute (red) 48V, 48VL, 48V Off N/A Toggles Input Solo Toggles 48V, 48VL,
and Off
Input Delay
(User Mode) Metering (PFL + Post-EQ)
Input Solo (yellow)
Input Mute (red) Input Delay in mS Input Delay
adjust Toggles Input Solo N/A
Polarity
(User Mode) Metering (PFL + Post-EQ)
Input Solo (yellow)
Input Mute (red) Polarity Inv/Norm N/A Toggles Input Solo Toggles Polarity Inv/
Norm
Low Cut Mode (User)
In Low Cut Mode, turn a Rotary Encoder to adjust the frequency roll off point for the selected input.
To toggle an input’s High-Pass Filter on or off, press and hold the input’s Rotary Encoder for one
second or longer. The roll off point is adjustable from 40 to 320 Hz in increments of 10 Hz. High-Pass
Filter status is displayed on the 788T Main LCD Display while in Low Cut Mode.
Input Limiter Mode (User)
In Input Limiter Mode, press and hold the input’s Rotary Encoder for one second or longer to toggle
an input’s Limiter on or off. Input Limiters are not available when set to sampling rates of 88.2 kHz
and above. Limiter status is displayed on the 788T Main LCD Display while in Input Limiter Mode.
Phantom Power Mode (User)
In Phantom Power Mode, press and hold the input’s Rotary Encoder for one second or longer to
toggle an input’s Phantom Power between 48V, 48VL or Off. Phantom Power status is displayed on
the 788T Main LCD Display while in Phantom Power Mode.
Input Delay Mode (User)
In Input Delay Mode, turn an input’s Rotary Encoder to adjust the Input Delay for the respective in-
put. Input Delay is adjustable from 0 to 30 mS in increments of .1 mS. Maximum Input Delay values
788T/788T-SSD User Guide and Technical Information
138
v. 3.02 Features and specifications are subject to change. Visit www.sounddevices.com for the latest documentation.
