Sound Devices 788T - Manual (Page 127)

Function Switches 1, 4
(Momentary)
Switches 2, 3
(Latching)
Notes
Momentary Toggle Toggle Only
Rotary Switch Push
Button    Acts as Rotary Switch Push Button
Performs action defined in Setup Menu option HP:
Rotary Push Function
Rotary Switch Up    Acts as Rotary Switch Up
(Toggles headphone routings in Main LCD display)
Rotary Switch Down    Acts as Rotary Switch Down
(Toggles headphone routings in Main LCD display)
PFL 1-8    Sw 1,4 - Press and release to enter Input Settings
Window, press and release again to exit
Sw 2,3 - On enters Input Settings Window, Off exits
Slate (CL-8, CL-9 only)  Press and hold to activate Slate Mic, release to
deactivate the Slate Mic. CL-8 or CL-9 has to be
connected to activate the Slate Mic.
Setup Menu Options   Action varies as defined by shortcut setting
Jam Rx Time Code   Action varies as defined by shortcut setting
Jam Zeros   Action varies as defined by shortcut setting
Jam Value   Action varies as defined by shortcut setting
Edit Value   Action varies as defined by shortcut setting
Edit U-Bits   Action varies as defined by shortcut setting
Increment Scene  Increments Scene Name/Number
False Take  Enters False Take prompt
Connect FireWire  Initiates Computer Connection
Increase LED
Brightness  Increases LED brightness by one step
Decrease LED
Brightness  Decreases LED brightness by one step
Edit Current Take   Enters current take’s Edit Menu
Edit Current Take
Notes   Enters current take’s Notes field
Rename Current Take   Enters current take’s Rename field
Assigning any other functions than the ones listed above to the CL-2 Logic Switches may result in unpre-
dictable behavior.
Hardw
are Controllers
10
788T/788T-SSD User Guide and Technical Information
119
