3. Press in on the Rotary Switch to toggle the routing status of a selected destination. The Slate
Mic is routed to all of the highlighted options.
Slate Mic Level
The Slate Mic gain level can be adjusted from -46 to 6 dB in 1 dB increments. Follow these steps to
adjust the gain of the Slate Mic.
1. From the 788T’s Main LCD Screen, press and hold the SLATE butt on on the CL-8’s Left Panel.
2. Turn the Rotary Switch to adjust the gain. The gain level is momentarily displayed in the
Sample Rate fi eld of the LCD display.
3. Release the SLATE butt on to deactivate the Slate Mic.
