2 playback – Banner PresencePLUS P4 Series User Manual
Page 217
3. Press Record. After choosing which images to save and where to save them, the last step is to
press the red Record button found midway down the page. As the images are saved, the file
names will appear in the Playback List window. Press the record button or the square Stop button
to stop recording.
10.13.2 Playback
The Playback feature is available whenever the vision sensor is in Run mode but the Start button has not been
pushed. To enter Playback mode on a currently running sensor, hit the Stop button. Clicking on the Playback
tab will bring up the screen shown below left. This screen is almost exactly the same as the Record screen
shown earlier: the only differences are the title of the tab and the fact that the Record button is inactive.
217
Banner Engineering Corp. - Minneapolis, MN USA - www.bannerengineering.com
Tel: 763.544.3164
P/N 000000
Run Screen
7/2009
