Description Value Data Label
1 = Tool executed successfully
0 = Tool did not find a point to use as a reference
1 or 0 Success
Tool processing time for the current inspection. ms Execution Time
Fastest recorded tool processing time since the start of the
inspection or since power-up. ms Execution Time Min
Slowest recorded tool processing time since the start of the
inspection or since power-up. ms Execution Time Max
Color Match Test Result
% Color Match Percent
% Match Percent Threshold
The grayscale brightness. This value ranges from 0 to 255. whole number Brightness
The grayscale brightness lower limit. This value ranges from 0 to
255. whole number Brightness Lower Limit
The grayscale brightness upper limit. This value ranges from 0 to
255. whole number Brightness Upper Limit
Communication Tool Exportable Results: Barcode Tool
Description Value Data Label
User-defined name string Tool Name
Success
Tool processing time for the current inspection. ms Execution Time
Fastest recorded tool processing time since the start of
the inspection or since power-up. ms Execution Time Min
Slowest recorded tool processing time since the start of
the inspection or since power-up. ms Execution Time Max
Max Time Exceeded
whole number Number Found
Coordinates of Barcodes Found
Barcode Type
Symbol Type
whole number Number of Barcode Data
Elements Read
Barcode Data Read
Barcode Read Status
2-D Symbol Dimensions
