Communication Tool Exportable Results: Measure Tool
Description Value Data Label
User-defined name string Tool Name
Tool processing time for the current inspection. ms Execution Time
Fastest recorded tool processing time since the start of the inspection
or since power-up. ms Execution Time Min
Slowest recorded tool processing time since the start of the inspection
or since power-up. ms Execution Time Max
Total distance from the points selected for Tool One and Tool Two.î pixels Distance
Horizontal component (X) of the total distance. pixels Distance X
Vertical component (Y) of the total distance. pixels Distance Y
X, Y coordinates of the origin point. pixels (X,
Y) Origin Point
X,Y coordinates of the point selected for Tool One. pixels (X,Y) Measure Location Point
1
X,Y coordinates of the point selected for Tool Two. pixels (X,Y) Measure Location Point
2
Communication Tool Exportable Results: String Tool
Description Value Data Label
User-defined name string Tool Name
1 = Tool overall results passed.
2 = Tool overall results failed.
1 or 0 Success
Tool processing time for the current inspection. ms Execution Time
Fastest recorded tool processing time since the start of the inspection
or since power-up. ms Execution Time Min
Slowest recorded tool processing time since the start of the inspection
or since power-up. ms Execution Time Max
Max Time Exceeded
Operand 1
Operand 2
Operation Result
Communication Tool Exportable Results: Test Tool
Description Value Data Label
User-defined name string Tool Name
