In the application shown above, as each plastic formed part comes past the Vision sensor, an inspection is
performed. If the part is not shaped correctly as shown here, the inspection fails.
2.1.2 PresencePLUS
®
P4 Components
The PresencePLUS P4 system consists of the Sensor and a PC with PresencePLUS software and the
appropriate connections. The Sensor requires lighting and a trigger device, and an optional video monitor can
be connected.
Note: The trigger device can be any 10-30V dc photoelectric sensor (PNP or NPN) or a device with a
similar output.
