Description
Value
Data Label
Slowest recorded tool processing time since the start of the
inspection or since power-up.
ms
Execution Time Max
X, Y coordinates of the point from ROIs will rotate.
pixels (X, Y)
Rotation Origin
Rotational value of the first pattern found.
degrees
Best Match Rotation
X, Y coordinates of the first pattern found.
pixels (X, Y)
Best Match Location
Point
Percent match of the first patttern found.
20-100%
Best Match %
Communication Tool Exportable Results: Pattern Find Tool
Description
Value
Data Label
User-defined name
string
Tool Name
1 = Tool executed successfully
0 = Tool did not find a point to use as a reference
1 or 0
Success
Tool processing time for the current inspection.
ms
Execution Time
Fastest recorded tool processing time since the start of the
inspection or since power-up.
ms
Execution Time Min
Slowest recorded tool processing time since the start of the
inspection or since power-up.
ms
Execution Time Max
Minimum percent the current pattern must match the reference
pattern to be considered a match.
20 - 100%
Match Acceptance Level
Range Min
Maximum percent the current pattern must match the reference
pattern to be considered a match.
20 - 100%
Match Acceptance Level
Range Min
X, Y coordinates of the point from which ROIs will rotate.
pixels (X,Y)
Rotation Origin
Rotational value of the first pattern found.
degrees
First Match Rotation
X,Y coordinates of the first pattern found.
pixels (X, Y)
First Match Location Point
Percent match of the first pattern found.
15 - 100%
% Match of First Pattern
Found
Communication Tool Exportable Results: Blob Detect Tool
Description
Value
Data Label
User-defined name
string
Tool Name
Tool processing time for the current inspection.
ms
Execution Time
Fastest recorded tool processing time since the start of the
inspection or since power-up.
ms
Execution Time Min
Slowest recorded tool processing time since the start of the
inspection or since power-up.
ms
Execution Time Max
Number of Blobs found.
whole number
Count
