Note:

Because there is no flow control for the serial connections, the sensor wil not detect or log a lost or broken
connection

8.3 Overview of Testing the Communication Tool

1. Connect the Sensor to a PC using a crossover Ethernet cable (STPX. ) or the serial pins on the

Sensor cable.

2. Start an inspection that has a configured Communication tool. For details about configuring the

Communication.

3. Start HyperTerminal or Telnet.
4. Trigger the Sensor.
5. Look in HyperTerminal or Telnet to see if the data has updated.
