7.3.1 Edge Tool
The Edge tool finds and marks the position of all edges along an
ROI
line. It detects and counts transitions
between bright and dark pixels. The total number of edges can be counted, and the position of each edge can
be found. Edge position information can be used for distance or angle measurement.
Usage
• Measure the height and width of a part
• Count the pins on a resistor
• Measure the height of a needle
• Measure the deflection of an automotive gauge
• Detect the edge of a web
• Verify that a bottle cap is on completely
Fields
The following are fields on the Edge tool Input tab:
•
Threshold Type7.2.1.2 Threshold Type
on page 113
•
on page 118
•
Edge Tool Results7.3.1.4 Edge Tool Results
on page 109
Supported Platforms
BCR/BCR
1.3
GEO/GEO
1.3
EDGE/EDGE
1.3
AREA/AREA1.3
OMNI/OMNI
1.3
OMNI Color
ProII/ProII
1.3
ProII Color
No
No
Yes
No
Yes
Yes
Yes
Yes
Edge Tool Input Tab
