7.3.2 Object Tool
The Object tool detects the edges of dark and bright segments in an ROI. The Object tool measures the widths
of every dark and light segment along the ROI. The Object tool calculates the midpoint for every object, and
counts the total number of objects. The midpoint can be used to measure distances and angles. Each object
can have unique size limit, or all objects may have the same size limit.
Usage
• Measure the width of a label
• Locate the center of a box on a conveyor
• Measure the gaps between stamped parts on a Web.
Fields
The following are fields on the Object tool Input tab:
•
Threshold Type7.2.1.2 Threshold Type
on page 113
•
on page 118
•
Object Tool Results7.3.2.4 Object Tool Results
on page 119
Supported Platforms
BCR/BCR
1.3
GEO/GEO
1.3
EDGE/EDGE
1.3
AREA/AREA1.3
OMNI/OMNI
1.3
OMNI Color
ProII/ProII
1.3
ProII Color
No
No
Yes
No
Yes
Yes
Yes
Yes
Object Tool Input Tab
