Windows CE Operating System Chapter 4
FTP Server Configuration
The FTP Server tab in the Network Server Configuration dialog box configures
settings that are used for exchanging files over a network. These are standard
Microsoft Windows CE parameters.
The default FTP configuration lets any user establish an FTP connection to the
HMI terminal by logging in anonymously and downloading files from the FTP
default directory (\Temp).
TIP Always click OK to apply new settings. You are asked if you want to restart the
service immediately.
Table 30 - FTP Server Parameters
FTP Parameters Description Default
General
Default Directory Specifies a storage location on your HMI terminal for transferring files.
This is the directory that users come to when they first connect to the FTP server. \Temp\
Idle Timeout Specifies the time in seconds before the inactive control connections are closed during a data transfer. An FTP session
requires one control connection, plus one data connection during file transfers.
Without a timeout, the FTP server process can be left pending indefinitely if the corresponding client crashes without
closing the control connection. 300 seconds
(5 minutes)
Debug Output Channels Specifies the number of debug output channels. 2
Debug Output Mask Specifies the port number of the output mask used for debugging. 23
Base Directory Specifies the path where the FTP log file and other support files are stored. \Windows
Log Size Specifies the maximum size of the file that logs FTP activities. The log file is stored in the base directory.
A new log file is created when the current log file is the maximum size. 4096 bytes
Security Parameters
Use Authentication Check this option to require a valid NTLM user name and password to access the FTP server.
If authentication is enabled, you must enter one or more valid user names in the User List field.
NTLM user accounts are defined in the User Account Manager of the control panel. Enabled (checked)
Allow Anonymous Logins Check this option to let anyone connect to the ftp server. Anonymous logins do not require a user name and password. Enabled (checked)
Allow Anonymous Uploads Check this option to let users logged in anonymously to upload (or write) files to the FTP server (or default directory).
If unchecked, users logged in anonymously can download (or copy) files from the server. Disabled (unchecked)
Allow Anonymous VRoots Check this option to let users logged in anonymously access virtual roots. Disabled (unchecked)
User List Specifies the NTLM users that can access the ftp server and exchange files to or from the default directory.
When selected, you can enter a list of NTLM user names, separated by semicolons, in the field that opens at the bottom of
the dialog box. User names and passwords are defined in the User Account Manager of the control panel. None
