76 Rockwell Automation Publication 2711PC-UM002B-EN-P - April 2014
Chapter 4 Windows CE Operating System
Windows Explorer From the desktop, you can access Windows Explorer in several ways:
• Open My Device icon on the desktop.
• Choose Start>Programs>Window Explorer.
Besides the typical system folders, a few folders contain items that are specific to
the PanelView Plus 6 Compact terminals.
Taskbar The taskbar has icons to access the Start menu, terminal IP information, current
language and time, desktop access, input panels, and open programs.
You can turn the taskbar on or off by choosing Start>Settings>Taskbar and Start
Menu then checking or clearing the Auto Hide checkbox.
Input Panels Different soft keyboards or input panels are available for entering data. You can
access these input panels from the taskbar.
• Keyboard and large keyboard
• CHT Chajei (Chinese)
• CHT Phonetic (Chinese)
• MS Kana (Japanese)
• MS Roma (Japanese)
• No IM - no input method selected (default)
Folder Content
Application Data Contains FactoryTalk View Machine Edition application files.
Path: \Application Data\Rockwell Software\RSViewME\Runtime
VFS (Virtual File System) Contains firmware files and back-up/restore files for the current system image.
Path: \VFS\Platform Firmware
TIP On touch screen terminals, touch the bottom of the display to recover the
taskbar in Auto Hide mode.
TIP You can hide the view of an input panel from the taskbar by choosing the
No IM option.
