Check Voltages and Temperatures
Check the battery voltage, processor temperature, and display temperature.
Check the System Event Log
Check the system event log for errors and unexpected behaviors:
• From FactoryTalk View ME Station Configuration mode, press Terminal
Settings>System Event Log. Refer to View and Clear the System Event
Log on page 64 .
• From the control panel, open the Hardware Monitor and click the System
Event Log tab. Refer to System Event Log on page 81 .
Start-up Messages and Codes The splash screen reports actions and status conditions that occur during startup.
This includes firmware and hardware revision information.
Figure 14 - Start-up Splash Screen
Table 53 - Checking Voltage and Temperature Conditions
Check for These Conditions Where What to Do
Battery voltage < 2.75V DC • From the terminal desktop: Refer
to Monitors on page 82
• From FactoryTalk View ME Station
Configuration mode:
Refer to
View Terminal Information
on page 64
Replace the battery if needed.
Logic board
temperature >95 °C (203 °F) • From the terminal desktop: Refer
to Monitors on page 82
Check for obstructed airflow in
the chassis and attempt to
moderate the ambient
temperatures within the
enclosure and surroundings.
Display temperature >55 °C (131 °F) • From terminal desktop: Refer
to Temperatures on page 94 :
• From FactoryTalk View ME Station
Configuration mode:
Refer to
View the Display
Temperature on page 67
INIT
© 2014 Rockwell Automation, Inc.
All Rights Reserved.
N3
Status or
Error Code
State Message
Logic Module
Hardware Revision
Boot Loader
Firmware Revision
Operating System
Firmware Revision
Progress Bar
RSLinx Enterprise
Firmware Revision
Font Collection
Firmware Revision
Machine Edition
Firmware Revision
FactoryTalk ViewPoint
Firmware Revision
BL 02.12
OS 02 .14
01 OSEX
APP
APPEX
SERV
COMM
FONT
06 .10
01 .03
02 .51
02.10
01.01
05.51
OS Extensions
Firmware Revision
FactoryTalk Services
Firmware Revision
